PUMPING SOLIDS

ELMRIDGE Liqui-Jet & Gas-Jet Solids Eductors

ELMRIDGE Liqui-Jet Eductors

ELMRIDGE Liqui-Jet Eductors

Pumping Solids Using Motive Liquid

Mixing and pumping free-flowing granular solids and powders

ELMRIDGE Liqui-Jet Solids Eductors use liquid under pressure as the motive fluid, and effectively pump or convey granular solids or slurries. Inlet liquid pressures for this type of eductor are typically in a range from 10 to 100 psig. Solids flowrate and conveying distance are a function of eductor selection, as well as material properties and downstream piping considerations. Liqui-Jet Solids Eductors are available with Dry-Feed hoppers and Washdown style hoppers. The Washdown style of feed hopper can dramatically increase the Suction Capacity and available Discharge Pressure of a given Eductor. This is achieved by ‘sealing’ the suction of the Eductor and reducing the amount of ambient air entrained with the solids. TLS Series‘ Liqui-Jet Solids Eductors for Dry-Feed applications, and TLST Series‘ Liqui-Jet Solids Eductors for use with Washdown Hoppers both combine the most efficient ratio of Motive liquid consumption with available Suction Capacity and Discharge Pressure. Liqui-Jet Solids eductors are typically available from stock in PVC, CPVC, Bronze/Brass, Cast Iron/Steel, 316L Stainless Steel, and all Carbon Steel construction. Abrasion resistant Ceramic Liners are also available. Other materials are available upon request. Threaded or flanged, or Sanitary connections are standard.

ELMRIDGE Liqui-Jet Eductors and Gas-Jet Siphons are Self-Priming and have no moving parts!

See the ELMRIDGE ‘ME Series’ Liqui-Jet Mixing Eductor datasheet for pumping liquids and suspensions or slurries with equipment mounted inside the process vessel.

ELMRIDGE Liqui-Jet Eductors are an efficient, economical means of pumping liquids of slurries.

ELMRIDGE Gas-Jet Siphons are typically used for pumping liquids or slurries when Motive Steam is available.

ELMRIDGE Gas-Jet Siphons

ELMRIDGE Gas-Jet Siphons

Pumping Solids Using Motive Compressed Gas

Conveying free-flowing granular solids and powders

Gas-Jet Solids Eductors use compressed gas (usually compressed air), as the Motive fluid, and effectively pump or convey dry granular solids. Standard eductors use low pressure/high volume blowers as the compressed gas source. Inlet pressures for this type of eductor are typically in a range from 2 to 15 psig. Solids flowrate and conveying distance are a function of eductor selection, as well as material properties, and downstream piping considerations. This type of eductor is usually gravity fed. TGS Series‘ Gas-Jet Solids Eductors combine the most efficient ratio of Motive compressed gas consumption with available Suction Capacity and Discharge Pressure. Gas-Jet Solids eductors are typically available from stock in Bronze/Brass, Cast Iron/Steel, 316L Stainless Steel, and all Carbon Steel construction. Abrasion resistant Ceramic Liners are also available. Other materials are available upon request. Threaded or flanged connections are standard. ‘TGST Series’ Gas-Jet Solids Eductors for higher inlet gas pressures are also available, and are typically used for vacuum applications where a vacuum hose is used to draw solids material into the eductor.
